顆粒狀糖果包裝機設計（含全套CAD圖紙）
- 文件介紹：
- 該文件為 rar 格式，下載需要 20 積分
-
- 顆粒狀糖果包裝機設計（含全套CAD圖紙）
摘要：顆粒狀糖果包裝機設計是典型的機械系統設計，它不僅包括機構的尺寸、強度設計，還包括了傳動機械系統設計。本設計主要是針對圓臺柱狀巧克力糖的鋁箔紙包裝。設計主要內容有三方面：設計方案設計、機械手及進出糖機構設計與傳動系統鏈設計。
機械手及進出糖機構設計是本設計功能能否執行的靈魂，它也是本設計的設計重點之一。它要實現巧克力糖的輸入、折邊、抄底邊、等等功能，直到最后由輸送帶輸出。整個系統功能實現中，機械手要實現的是夾糖、折邊、轉送等重要功能，因此對機械手的形狀、夾緊力及轉位角度也提出了不同的設計要求，設計機械手時，也始終回繞著這幾點進行。
傳動系統設計，作為一個動作執行系統，動力是必不可少的，當然對動力的傳遞系統也就顯得尤其重要了。系統功能中要實現機械手轉位、送糖盤轉位、供紙、剪紙、抄紙、接糖、頂糖及撥糖等功能，它們都需要不同大小的動力，這就需要傳動系統的調節。如在機械手的轉位功能中，為實現間歇的轉位功能就得通過傳動鏈中的槽輪機構來實現，該機構要保證機械手在轉到位后，有一定的停留時間，從而為頂糖、接糖及撥糖功能的實現提供必要的機械動作執行時間。設計好的包裝機機構正常的生產率為120r/min，且其生產率可在70～130r/min.
關鍵詞：包裝機，巧克力糖包裝，機械手。
第 2 頁
畢業設計 顆粒狀糖果包裝機的設計
Abstract: The grain candy packer design is a typical machine system design. It not only included the organization's size, strength...etc. the design. And it still included the design of the transmission system. This design primarily aims at the circle pillar chocolates' aluminum foil packing. The design only contents contain three sides: Design project design, machine hand and I/O sugar mechanism design and the transmission system design.
It is Soul whether the function of the machine hand and I/O sugar mechanism’s design can carry out in this design. It is also one of the design points of this design. It wants to realize the importation, fold of the chocolates the sides, etc. the function. Until it finally be output by belt conveyer. In whole system function realizes, the machine hand realizes many important function, for example: clip the sugar, fold of the chocolates the sides, transfer...etc. Therefore to the shape of the machine hand, clip the tight dint and turn the angle also bring upped the different design request. When designed the machine hand, it is also proceeding with the center of these points.
System, motive is necessary. Certainly it is particularly important of the power transmission system. In the system function, it must realize moving the machine hand, moving the sugar dish, providing the paper, cutting paper, curling, connecting the sugar, crest the sugar and dialing the sugar etc. All these functions need the different power. It can be controlled with the transmission system. Such as the function of turning machine hand, for realizing a function of intermittent turning it needs the sheave of the transmission to regulate. After the machine turned the assurance position, the mechanism wants to have certainly stop over time, it can take enough time to crest sugar, connect the sugar and dial sugar. The transmission system still guaranteed the normal rate of production of packer to 120 r/ min .At the same time it can be controlled the rate of production at 70 ～ 130 r/ min.
Key words: Packer, chocolates packing, machine hand.
第 3 頁
畢業設計 顆粒狀糖果包裝機的設計
目錄
前言........................................................................................................................................7
第一章 糖果包裝機方案設計............................................................................8
1.1 設計任務抽象化...................................................................................................................8
1.1.1建立黑箱....................................................................................................................................8
1.1.2功能分解....................................................................................................................................9
1.2確定工藝原理..........................................................................................................................9
1.3確定技術過程........................................................................................................................10
1.4引進技術系統，確定邊界.............................................................................................10
1.5確定功能結構.........................................................................................................................11
1.5.1 總功能.....................................................................................................................................11
1.5.2 功能分解...............................................................................................................................11
1.6方案確定..................................................................................................................................12
1.6.1尋找技術物理效應和功能載體，功能元求解目錄表...........................................................12
1.6.2巧克力糖包裝系統解..............................................................................................................12
1.6.3巧克力糖包裝裝置的評價表..................................................................................................14
1.6.4確定最佳方案..........................................................................................................................14
第二章傳動系統設計.............................................................................................15
2.1傳動系統結構簡圖.............................................................................................................15
2.2 選用電機.................................................................................................................................15
2.3帶輪設計..................................................................................................................................16
第 4 頁
畢業設計 顆粒狀糖果包裝機的設計
2.3.1帶輪優缺點..............................................................................................................................16
2.3.2 選用帶輪要求.........................................................................................................................16
2.3.3 帶輪設計要求.........................................................................................................................17
2.3.4 帶輪設計過程.........................................................................................................................17
2.4鏈輪設計..................................................................................................................................21
2.4.1鏈傳動優缺點..........................................................................................................................21
2.4.2鏈傳動的設計過程..................................................................................................................21
2.5齒輪的設計.............................................................................................................................25
2.5.1齒輪材料..................................................................................................................................25
2.5.2 分配軸上螺旋齒輪的尺寸計算.............................................................................................25
2.5.3 機械手及送糖軸上的螺旋齒輪的尺寸計算.........................................................................26
第三章機械手及進出糖機構設計...............................................................27
3.1夾持裝置設計........................................................................................................................27
3.1.1 設計要求...................................................................................................................................27
3.1.2 基本結構如圖.........................................................................................................................27
3.1.3夾緊力P夾計算..........................................................................................................................27
3.1.4 彈簧力P彈簧計算.....................................................................................................................28
3.1.5 開閉角а的計算...................................................................................................................29
3.2凸輪設計..................................................................................................................................29
3.2.1 選擇凸輪類型.........................................................................................................................29
3.2.2 凸輪材料選擇.........................................................................................................................30
3.2.3凸輪尺寸計算..........................................................................................................................30
3.2.4 凸輪強度計算.........................................................................................................................31
3.3棘輪設計..................................................................................................................................32
3.3.1棘輪材料選擇..........................................................................................................................32
3.3.2棘輪形狀確定..........................................................................................................................32
3.4 六槽槽輪機構設計............................................................................................................33
3.4.1 槽輪分類及材料選擇.............................................................................................................33
3.4.2 槽輪結構設計及尺寸計算.....................................................................................................33
第四章其它機構原理.............................................................................................36
第 5 頁
畢業設計 顆粒狀糖果包裝機的設計
4.1 頂糖、接糖機構示意圖.................................................................................................36
4.2抄紙和撥糖機構示意圖..................................................................................................37
第五章 巧克力糖包裝機工作循環圖............................................................38
5.1 機械手Ⅰ工位段.................................................................................................................38
5.2 機械手Ⅱ工位段.................................................................................................................39
致 謝..............................................................................................................................40
參考文獻...........................................................................................................................41
英文翻譯..............................................................................................錯誤！未定義書簽。
第 6 頁
畢業設計 顆粒狀糖果包裝機的設計
前言
時間轉瞬即逝，轉眼之間四年的大學生涯就要結束了，回首四年...
